DS1X02X0 Automotive Diagnostic Tool Test... - FCC ID 2ASC7DS1X02X0
FCC ID 2ASC7DS1X02X0
Test setup photos
Automotive Diagnostic Tool
Document preview loads when visible.
Document Details
| FCC ID | 2ASC7DS1X02X0 |
|---|---|
| Document ID | 7818539 |
| Document Type | Test Setup Photos |
| Description | Test setup photos |
| Applicant | OBDSPACE TECHNOLOGY CO,.LTD |
| Equipment Class | Automotive Diagnostic Tool |
| Product Code | DS1X02X0 |
| Application ID | UMJPrUIB2K+KFQ4+XvuQiA== |
| Application Purpose | Original Equipment |
| Application Date | 2024-11-13 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0028167070 |
| Test Firm | Shenzhen CTL Testing Technology Co., Ltd. |
| Certified By | Frank Hao |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2024-11-13 |
| Available | 2024-11-13 |
| Created | 2024-11-06 |
| Modified | 2024-11-06 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 449027 |
| File SHA-256 | c9a2b98ec6ec1f19cfd9ebc6def37050401c2fc17c23ef18b58b799d26efac8b |
| PDF Metadata Author | Windows 用户 |
| PDF Metadata Producer | Microsoft® Word 2013 Microsoft® Word 2013 |
| FCC.gov Sources | FCC.gov 7818539, FCC.gov 7818146 |
