EO009 Wireless Earphones Test Setup Photos - FCC ID 2ASDIEO009
FCC ID 2ASDIEO009
T Setup Photos
Wireless Earphones
Document preview loads when visible.
Document Details
| FCC ID | 2ASDIEO009 |
|---|---|
| Document ID | 6013554 |
| Document Type | Test Setup Photos |
| Description | T Setup Photos |
| Document Title | BL-SZ2241151-AR RF test setup photo |
| Applicant | Tiinlab Corporation |
| Equipment Class | Wireless Earphones |
| Product Code | EO009 |
| Application ID | DtuBAr9OnX4ePb4cDg1rbA== |
| Application Purpose | Original Equipment |
| Application Date | 2022-07-22 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0028116580 |
| Test Firm | Shenzhen BALUN Technology Co., Ltd. |
| Certified By | XUEWEN WU |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 01/17/2023 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2022-07-22 |
| Available | 2023-01-17 |
| Created | 2022-06-23 |
| Modified | 2022-06-23 |
| Pages | 4 |
| File Type | Adobe Acrobat PDF |
| File Size | 846159 |
| File SHA-256 | ee780b27005e3db4d22d5f20e3b42b6c6877f2a4e893812bd7dfe4abe14f0318 |
| PDF Metadata Author | 刘柳 |
| PDF Metadata Producer | Microsoft® Word 2019 刘柳 |
| FCC.gov Sources | FCC.gov 6013554, FCC.gov 6013461 |
