D1600 Portable Label Maker Teardown... - FCC ID 2ASRB-D1600

FCC ID 2ASRB-D1600

Internal photos

Portable Label Maker

by Zhuhai Quin Technology Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2ASRB-D1600
Document ID5816740
Document TypeInternal Photos
DescriptionInternal photos
Document TitleATTACHMENT PHOTOGRAPHS OF EUT
ApplicantZhuhai Quin Technology Co., Ltd.
Equipment ClassPortable Label Maker
Product CodeD1600
Application IDa4lhBFdwfTsQ80hE2oeyWA==
Application PurposeOriginal Equipment
Application Date2022-04-13
Frequency Range2402-2480 MHz
FRN0028328375
Test FirmShenzhen Microtest Co., Ltd.
Certified ByChloe Xu product manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2022-04-13
Available2022-04-13
Created2022-04-08
Modified2022-04-08
Pages4
File TypeAdobe Acrobat PDF
File Size2950375
File SHA-256feb23ceccf0a4b82381897d922fa234e306a7eec7e6c775b5491d8aa4aa057e7
PDF Metadata Author高莹莹 WwW.YlmF.CoM
PDF Metadata Producer高莹莹 Adobe PDF Library 15.0
FCC.gov SourcesFCC.gov 5816740, FCC.gov 5816522
