FC6100 FC6100 Mask-Mounted Sensor Teardown... - FCC ID 2AT3JFC6100
FCC ID 2AT3JFC6100
Internal Photos
FC6100 Mask-Mounted Sensor
Document preview loads when visible.
Document Details
| FCC ID | 2AT3JFC6100 |
|---|---|
| Document ID | 4435939 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | DesignRealityLimited |
| Equipment Class | FC6100 Mask-Mounted Sensor |
| Product Code | FC6100 |
| Application ID | jm0mi9NpF0r06Rw8zdQV0w== |
| Application Purpose | Original Equipment |
| Application Date | 2019-09-09 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0028661676 |
| Test Firm | Element Materials Technology Warwick Ltd |
| Certified By | Graham Wilson Design Director |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2019-09-09 |
| Available | 2019-09-09 |
| Created | 2019-07-23 |
| Modified | 2019-07-23 |
| Pages | 4 |
| File Type | Adobe Acrobat PDF |
| File Size | 1528986 |
| File SHA-256 | 576a139e42cf1a182b4749fa20236a61decd6ad06da7664e9488fccec22b3b37 |
| PDF Metadata Author | Josh Batty |
| PDF Metadata Producer | Microsoft® Word 2013 Microsoft® Word 2013 |
| FCC.gov Sources | FCC.gov 4435939 |
