2018BP4 bluetooth headphone Test Setup Photos - FCC ID 2ATLZ-2018BP4

FCC ID 2ATLZ-2018BP4

Test setup photos

bluetooth headphone

by Dongguan CQX Electronic Technology Co., Ltd

Document preview loads when visible.

Document Details

FCC ID2ATLZ-2018BP4
Document ID4330110
Document TypeTest Setup Photos
DescriptionTest setup photos
ApplicantDongguan CQX Electronic Technology Co., Ltd
Equipment Classbluetooth headphone
Product Code2018BP4
Application IDK3dcyeS9djb71CofCIXFBA==
Application PurposeOriginal Equipment
Application Date2019-06-24
Frequency Range2402-2480 MHz
FRN0028552776
Test FirmShenzhen LCS Compliance Testing Laboratory Ltd.
Certified ByYi Xiong The general manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2019-06-24
Available2019-06-24
Created2019-06-20
Modified2019-06-20
Pages2
File TypeAdobe Acrobat PDF
File Size417588
File SHA-256e2f4f9ef96d78c40a25aa3c0b700c0c77f9ecd4e9eb00c209891b337fc7a7040
PDF Metadata AuthorTian
PDF Metadata ProducerMicrosoft® Word 2016 Microsoft® Word 2016
FCC.gov SourcesFCC.gov 4330110
