RA05 LoRa Module External Photos - FCC ID 2ATPO-RA05

FCC ID 2ATPO-RA05

External Photos

LoRa Module

by Shenzhen Ai-Thinker Technology Co., Ltd

Document preview loads when visible.

Document Details

FCC ID2ATPO-RA05
Document ID7999546
Document TypeExternal Photos
DescriptionExternal Photos
Document Title55013
ApplicantShenzhen Ai-Thinker Technology Co., Ltd
Equipment ClassLoRa Module
Product CodeRA05
Application IDMQnr6bFO16EX4sEZl9wLjw==
Application PurposeOriginal Equipment
Application Date2025-01-21
Frequency Range2401-2482 MHz
FRN0028581585
Test FirmShenzhen CTB Testing Technology Co., Ltd.
Certified ByGuan Ning
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/20/2025
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2025-01-21
Available2025-01-21
Created2025-01-14
Modified2025-01-14
Pages3
File TypeAdobe Acrobat PDF
File Size716197
File SHA-2565fe3bcb7d2eafe19e13525833154510abc3d247feff497f85f7a9aaec0be9d9b
PDF Metadata AuthorJade
PDF Metadata ProducerMicrosoft® Word 2016 Microsoft® Word 2016
FCC.gov SourcesFCC.gov 7999546
