AIWB3 Wi-Fi & BT Module User Manual - FCC ID 2ATPO-AIWB3
FCC ID 2ATPO-AIWB3
Users Manual
Wi-Fi & BT Module
Document preview loads when visible.
Document Details
| FCC ID | 2ATPO-AIWB3 |
|---|---|
| Document ID | 6564548 |
| Document Type | Users Manual |
| Description | Users Manual |
| Applicant | Shenzhen Ai-Thinker Technology Co., Ltd |
| Equipment Class | Wi-Fi & BT Module |
| Product Code | AIWB3 |
| Application ID | T+AtIKoTMobo8bZUZl8Nxw== |
| Application Purpose | Original Equipment |
| Application Date | 2023-05-31 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0028581585 |
| Test Firm | Shenzhen CTB Testing Technology Co., Ltd. |
| Certified By | guan ning |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 11/27/2023 |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2023-05-31 |
| Available | 2023-11-27 |
| Created | 2023-05-26 |
| Modified | 2023-05-26 |
| Pages | 29 |
| File Type | Adobe Acrobat PDF |
| File Size | 1494527 |
| File SHA-256 | 0ff3fd9ce1e6d934f3b37f2a9ba7e2ae44d5f301e1ccb3f5af94f37c7f3491f8 |
| PDF Metadata Author | YLMF |
| PDF Metadata Producer | YLMF Adobe Acrobat Pro DC 18.9.20050 |
| FCC.gov Sources | FCC.gov 6564548 |
