XLB512 Micro component system External Photos - FCC ID 2ATW9-XL-B512

FCC ID 2ATW9-XL-B512

EXTERNAL PHOTO1

Micro component system

by Dongguan Yiertek Co., Ltd

Document preview loads when visible.

Document Details

FCC ID2ATW9-XL-B512
Document ID6226809
Document TypeExternal Photos
DescriptionEXTERNAL PHOTO1
ApplicantDongguan Yiertek Co., Ltd
Equipment ClassMicro component system
Product CodeXLB512
Application IDpSBj6VeBXwdAb5ROVz6jWg==
Application PurposeOriginal Equipment
Application Date2022-11-17
Frequency Range2402-2480 MHz
FRN0028630663
Test FirmEST Technology Co., Ltd.
Certified ByJune Wang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2022-11-16
Available2022-11-17
Created2022-11-15
Modified2022-11-15
Pages4
File TypeAdobe Acrobat PDF
File Size333164
File SHA-256fbac3b975800c2719dd7b1c5f0217121cef8aefdcecce47dd5b4e99748313f2d
PDF Metadata AuthorDELL
PDF Metadata ProducerDELL Adobe PDF Library 9.0
FCC.gov SourcesFCC.gov 6226809
