RMW2103 Smart Watch with BT Test Setup Photos - FCC ID 2AUYFRMW2103
FCC ID 2AUYFRMW2103
TestSetupPhotos_DTS
Smart Watch with BT
Document preview loads when visible.
Document Details
| FCC ID | 2AUYFRMW2103 |
|---|---|
| Document ID | 5796764 |
| Document Type | Test Setup Photos |
| Description | TestSetupPhotos_DTS |
| Applicant | Realme Chongqing Mobile Telecommunications Corp., Ltd. |
| Equipment Class | Smart Watch with BT |
| Product Code | RMW2103 |
| Application ID | KtxZZXpA45TVknM/5SbpAA== |
| Application Purpose | Original Equipment |
| Application Date | 2022-04-01 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0028939957 |
| Test Firm | Shenzhen Morlab Communications Technology Co. Ltd. |
| Certified By | Wendy Zhan |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 09/29/2022 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2022-04-01 |
| Available | 2022-09-29 |
| Created | 2022-03-30 |
| Modified | 2022-03-30 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 650499 |
| File SHA-256 | 3ffcd3bbc733fb3df0c8195cf8b960c9e567880a66de9ed56131c65cf645e76e |
| PDF Metadata Author | New User |
| PDF Metadata Producer | Microsoft® Word 2016 New User |
| FCC.gov Sources | FCC.gov 5796764 |
