E201 Label printer Teardown Internal Photos - FCC ID 2AV8C-E201
FCC ID 2AV8C-E201
Internal Photos
Label printer
Document preview loads when visible.
Document Details
| FCC ID | 2AV8C-E201 |
|---|---|
| Document ID | 4723878 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | ANNEX_Part 15C |
| Applicant | Tianjin Milabel Technology Co., Ltd. |
| Equipment Class | Label printer |
| Product Code | E201 |
| Application ID | hx7BDwiAd8zUKSF39/ugSg== |
| Application Purpose | Original Equipment |
| Application Date | 2020-05-14 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0029489846 |
| Test Firm | Waltek Testing Group (Shenzhen) Co., Ltd. |
| Certified By | Jandy so |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2020-05-14 |
| Available | 2020-05-14 |
| Created | 2020-05-13 |
| Modified | 2020-05-13 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 6199825 |
| File SHA-256 | 939f96adca49574c0dd189817faa0e19be7cb2ac24cae6b5dd5ce877aeee3cac |
| PDF Metadata Author | aaa |
| PDF Metadata Producer | Acrobat Distiller 9.3.2 (Windows) aaa |
| FCC.gov Sources | FCC.gov 4723878, FCC.gov 4723865 |
