AP8220 Wireless LAN Access Point Teardown... - FCC ID 2AVUGAP8220

FCC ID 2AVUGAP8220

Internal photos

Wireless LAN Access Point

by Alibaba Cloud Commputing Co.,Ltd

Document preview loads when visible.

Document Details

FCC ID2AVUGAP8220
Document ID4872473
Document TypeInternal Photos
DescriptionInternal photos
Document TitleATTACHMENT
ApplicantAlibaba Cloud Commputing Co.,Ltd
Equipment ClassWireless LAN Access Point
Product CodeAP8220
Application IDq8p8bHZrRxAgwuPnuLtjGQ==
Application PurposeOriginal Equipment
Application Date2020-08-28
Frequency Range5180-5240 MHz
FRN0029303393
Test FirmBTL Inc.
Certified BySHI XINGXING Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2020-08-25
Available2020-08-28
Created2020-08-07
Modified2020-08-07
Pages9
File TypeAdobe Acrobat PDF
File Size3913637
File SHA-2569aa0b50700c290ae89f27bf2f99a1f62ee6b5bdcd7d54da3c3bcdc5b747af222
PDF Metadata AuthorDOCK NEI
PDF Metadata ProducerDOCK Adobe PDF Library 19.8.103
FCC.gov SourcesFCC.gov 4872473, FCC.gov 4872446
