TCx EDGE Cam+

by Toshiba Global Commerce Solutions, Inc.

Document preview loads when visible.

Document Details

FCC ID2AW3T-6260-002
Document ID6573505
Document TypeID Label/Location Info
Description6260-002 LabelSml
Document TitleRAVEN label
ApplicantToshiba Global Commerce Solutions, Inc.
Equipment ClassTCx EDGE Cam+
Product Code6260002
Application ID6aLrbmOkH2NfZvYcyw0MtQ==
Application PurposeOriginal Equipment
Application Date2023-06-05
Frequency Range5180-5240 MHz
FRN0029806486
Test FirmDEKRA TESTING AND CERTIFICATION CO., LTD. LinKou
Certified ByStanley Wu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2023-06-05
Available2023-06-05
Created2023-05-11
Modified2023-05-11
Pages2
File TypeAdobe Acrobat PDF
File Size659177
File SHA-2560370b970aa2798f047ae34f17ebc6ed1c5328e4db4b13d4f95b752fc4f582a7e
PDF Metadata ProducerAdobe Illustrator 26.5 (Windows) Adobe PDF library 16.07
FCC.gov SourcesFCC.gov 6573505, FCC.gov 6573418, FCC.gov 6573308
