EWBLED22 EW Standard Bluetooth Module... - FCC ID 2AXDJ-EWBLED22

FCC ID 2AXDJ-EWBLED22

Test Setup Photos

EW Standard Bluetooth Module

by Jiangsu Tech-leading information technology Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AXDJ-EWBLED22
Document ID4904499
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleEXHIBIT C_TEST SETUP PHOTOGRAPHS for BLE
ApplicantJiangsu Tech-leading information technology Co., Ltd.
Equipment ClassEW Standard Bluetooth Module
Product CodeEWBLED22
Application IDjL2ipQJjQ1seF5CbHgKtaA==
Application PurposeOriginal Equipment
Application Date2020-09-14
Frequency Range2402-2480 MHz
FRN0029904190
Test FirmBay Area Compliance Laboratories Corp. (Kunshan)
Certified ByJing Liu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2020-09-14
Available2020-09-14
Created2020-09-04
Modified2020-09-14
Pages2
File TypeAdobe Acrobat PDF
File Size1139892
File SHA-256136cdbe2f742945ed2183b0d263ef000fac66a89a8462f21e1de0f831b257375
PDF Metadata Authorbaclks68
PDF Metadata Producerbaclks68 Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 4904499
