BE800 BE19000 Tri-Band Wi-Fi 7 Router... - FCC ID 2AXJ4BE800

FCC ID 2AXJ4BE800

EUTPhoto_Internal

BE19000 Tri-Band Wi-Fi 7 Router

by TP-Link Corporation Limited

Document preview loads when visible.

Document Details

FCC ID2AXJ4BE800
Document ID6458857
Document TypeInternal Photos
DescriptionEUTPhoto_Internal
ApplicantTP-Link Corporation Limited
Equipment ClassBE19000 Tri-Band Wi-Fi 7 Router
Product CodeBE800
Application IDjDoh+44rHq0Qw4Mvu+i2Hw==
Application PurposeOriginal Equipment
Application Date2023-04-21
Frequency Range6115-7115 MHz
FRN0029962685
Test FirmUL Verification Services (Guangzhou) Co., Ltd.
Certified BySarah Wang Regulatory Compliance Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2023-04-06
Available2023-04-21
Pages10
File TypeAdobe Acrobat PDF
File Size1630310
File SHA-256993f6061a00a5c8fd2d2d974a02182316db7c0f7285c8b3d5f8aa5907eba2043
PDF Metadata ProducerPyPDF3
FCC.gov SourcesFCC.gov 6458857, FCC.gov 6432304, FCC.gov 6431903
