RE815X AX5400 Tri-Band Wi-Fi 6 Range... - FCC ID 2AXJ4RE815X
FCC ID 2AXJ4RE815X
Antenna Spec
AX5400 Tri-Band Wi-Fi 6 Range Extender
Document preview loads when visible.
Document Details
| FCC ID | 2AXJ4RE815X |
|---|---|
| Document ID | 6227251 |
| Document Type | Test Report |
| Description | Antenna Spec |
| Applicant | TP-Link Corporation Limited |
| Equipment Class | AX5400 Tri-Band Wi-Fi 6 Range Extender |
| Product Code | RE815X |
| Application ID | jvjJb2AKQl1lXHAP843bLw== |
| Application Purpose | Original Equipment |
| Application Date | 2022-11-23 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0029962685 |
| Test Firm | MRT Technology (Taiwan) Co.,Ltd |
| Certified By | Marlin Chen Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2022-11-16 |
| Available | 2022-11-23 |
| Created | 2022-05-06 |
| Modified | 2022-05-06 |
| Pages | 7 |
| File Type | Adobe Acrobat PDF |
| File Size | 494226 |
| File SHA-256 | 4966fc51589c189b29a96f00a0c93f0c4d8ff943180aa3ac3e9cd2cd3cb4ad7d |
| PDF Metadata Author | suyongfeng |
| PDF Metadata Producer | Microsoft® Word 2013 Microsoft® Word 2013 |
| FCC.gov Sources | FCC.gov 6227251, FCC.gov 6227239 |
