BGW321 BGW320-500 Wireless Integrated ONT... - FCC ID 2AXXQBGW321
FCC ID 2AXXQBGW321
TSUP Antenna Pattern
BGW320-500 Wireless Integrated ONT Residential Gateway
Document preview loads when visible.
Document Details
| FCC ID | 2AXXQBGW321 |
|---|---|
| Document ID | 7828093 |
| Document Type | Test Setup Photos |
| Description | TSUP Antenna Pattern |
| Applicant | Humax Networks, INC |
| Equipment Class | BGW320-500 Wireless Integrated ONT Residential Gateway |
| Product Code | BGW321 |
| Application ID | deAPhM8Kdbeph5F9d8JUWQ== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2024-11-18 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0030115505 |
| Test Firm | Sporton International Inc. Hsinchu Laboratory |
| Certified By | Leo Huang Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2024-11-15 |
| Available | 2024-11-18 |
| Created | 2022-08-15 |
| Modified | 2024-11-13 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 839583 |
| File SHA-256 | 5f15c593612bc8e03e4f0d64bbf5e9789f5faaaf856ebb380d0c60c34f16def0 |
| PDF Metadata Author | Bunny |
| PDF Metadata Producer | Bunny Adobe PDF Library 17.11.238 |
| FCC.gov Sources | FCC.gov 7828093, FCC.gov 7828068 |
