KMHSB002 PC Gaming Soundbar Test Setup... - FCC ID 2AYP9KM-HSB002

FCC ID 2AYP9KM-HSB002

test setup photos

PC Gaming Soundbar

by Shenzhen YaFex E-Commerce Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AYP9KM-HSB002
Document ID5301390
Document TypeTest Setup Photos
Descriptiontest setup photos
ApplicantShenzhen YaFex E-Commerce Co., Ltd.
Equipment ClassPC Gaming Soundbar
Product CodeKMHSB002
Application IDDPtSRZ8olsDwcU7a79T8NQ==
Application PurposeOriginal Equipment
Application Date2021-06-21
Frequency Range2402-2480 MHz
FRN0030435077
Test FirmAttestation of Global Compliance (Shenzhen) Co., L
Certified ByMeilin Wu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2021-06-21
Available2021-06-21
Created2021-06-17
Modified2021-06-17
Pages2
File TypeAdobe Acrobat PDF
File Size529455
File SHA-256b9cb74013347eafd293a01d862b25a9c45cfc492c3f3fb21b2a527a7ec9cc76c
PDF Metadata AuthorAdministrator
PDF Metadata ProducerMicrosoft® Word 2010 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 5301390
