E50 Environmental Sensor Teardown Internal Photos - FCC ID 2AZ3JE50
FCC ID 2AZ3JE50
Internal Photos_Part 2
Environmental Sensor
Document preview loads when visible.
Document Details
| FCC ID | 2AZ3JE50 |
|---|---|
| Document ID | 7513895 |
| Document Type | Internal Photos |
| Description | Internal Photos_Part 2 |
| Applicant | Rhombus Systems, Inc |
| Equipment Class | Environmental Sensor |
| Product Code | E50 |
| Application ID | ukold5imAW96B30szXkoQA== |
| Application Purpose | Original Equipment |
| Application Date | 2024-08-05 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0030968606 |
| Test Firm | Wendell Industrial Co., Ltd |
| Certified By | Dave Gustafson Vice President of Hardware |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2024-07-29 |
| Available | 2024-08-05 |
| Created | 2024-07-16 |
| Modified | 2024-07-29 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 1842314 |
| File SHA-256 | 7b45b9df3bc0f15cd2bfb7b7fadaff9250a8d89cfa8c409da2744a430ebb5d95 |
| PDF Metadata Author | steven |
| PDF Metadata Producer | PDFsam Basic v4.2.10 SAMBox 2.3.4 |
| FCC.gov Sources | FCC.gov 7513895 |
