MBCAA Beacon Finder Card Teardown Internal... - FCC ID 2AZ94MBCAA

FCC ID 2AZ94MBCAA

Internal Photos

Beacon Finder Card

by Peak Design

Document preview loads when visible.

Document Details

FCC ID2AZ94MBCAA
Document ID8979193
Document TypeInternal Photos
DescriptionInternal Photos
ApplicantPeak Design
Equipment ClassBeacon Finder Card
Product CodeMBCAA
Application IDJ7M31WqnLnVmjfELXXU+EA==
Application PurposeOriginal Equipment
Application Date2026-01-12
Frequency Range2402-2480 MHz
FRN0031022429
Test FirmSHENZHEN STS TEST SERVICES CO.,LTD.
Certified ByPan Guanlong
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Modular EquipmentDoes not apply
Composite DeviceNo
Submitted2026-01-12
Available2026-01-12
Created2026-01-09
Modified2026-01-09
Pages3
File TypeAdobe Acrobat PDF
File Size699350
File SHA-256cde16fa032a1defc27f91879ccc3b5b2e57d5e39768cb1e4c3361dea88a625d6
PDF Metadata Authorleon chen
PDF Metadata Producerleon chen PDFdo.com 5.5.6.0
FCC.gov SourcesFCC.gov 8979193
