M3P2104 LEVEL 2 AC EV CHARGER Teardown... - FCC ID 2AZGWM3P-2104
FCC ID 2AZGWM3P-2104
Internal Photos
LEVEL 2 AC EV CHARGER
Document preview loads when visible.
Document Details
| FCC ID | 2AZGWM3P-2104 |
|---|---|
| Document ID | 5226349 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | MEASUREMENT/TECHNICAL REPORT |
| Applicant | Sichuan Weiyu Electric Co., Ltd |
| Equipment Class | LEVEL 2 AC EV CHARGER |
| Product Code | M3P2104 |
| Application ID | CY+kES7kOw/m1B8dczQU0w== |
| Application Purpose | Original Equipment |
| Application Date | 2021-04-28 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0030738314 |
| Test Firm | Bay Area Compliance Laboratories Corp. (Chengdu) |
| Certified By | Longbing Deng |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2021-04-28 |
| Available | 2021-04-28 |
| Created | 2021-04-19 |
| Modified | 2021-04-28 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 619603 |
| File SHA-256 | a06cc47b7107b3b76b9960fedf7fdca4dc2b3233841e2ba085bc38f34525dcf2 |
| PDF Metadata Author | Thomas Lui Micronics Computers Inc. |
| PDF Metadata Producer | Thomas Lui Adobe PDF Library 9.0 |
| FCC.gov Sources | FCC.gov 5226349, FCC.gov 5226334 |
