19311 SMALL BUT MIGHTY WALKIE TALKIES Block... - FCC ID 2BBVX19311

FCC ID 2BBVX19311

Block Diagram

SMALL BUT MIGHTY WALKIE TALKIES

by Ja-Ru (HK) Limited

Document preview loads when visible.

Document Details

FCC ID2BBVX19311
Document ID6795785
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleBlock
ApplicantJa-Ru (HK) Limited
Equipment ClassSMALL BUT MIGHTY WALKIE TALKIES
Product Code19311
Application ID4C3hGVXELzUKQmge6DvTEQ==
Application PurposeOriginal Equipment
Application Date2023-09-10
Frequency Range49.86 MHz
FRN0033952193
Test FirmIntertek Testing Services Hong Kong Ltd.
Certified ByKenneth Wong Assistant Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2023-09-10
Available2023-09-10
Created2023-09-05
Modified2023-09-05
Pages1
File TypeAdobe Acrobat PDF
File Size36734
File SHA-256502f34c0cdea7cf563f448bbc8a5d33ec2ea8c165d796ab41a2e34a1925526fc
PDF Metadata Authorcnleung
PDF Metadata Producercnleung Acrobat Distiller 20.0 (Windows)
FCC.gov SourcesFCC.gov 6795785
