S7 Smart Projector Test Setup Photos - FCC ID 2BCE6-S7
FCC ID 2BCE6-S7
Test Setup Photos
Smart Projector
Document preview loads when visible.
Document Details
| FCC ID | 2BCE6-S7 |
|---|---|
| Document ID | 8768107 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Applicant | SHENZHEN TOUMEI TECHNOLOGY CO LTD |
| Equipment Class | Smart Projector |
| Product Code | S7 |
| Application ID | onT3C9mtP/D8nbLAXrS7Rw== |
| Application Purpose | Original Equipment |
| Application Date | 2025-11-20 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0034102962 |
| Test Firm | Centre Testing International Group Co., Ltd |
| Certified By | Liting Nong |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Submitted | 2025-11-20 |
| Available | 2026-05-19 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 1309037 |
| File SHA-256 | 4d73cb54d5d6761702f0d77171da089d33a8d92e401b3456248a34b1604b22cd |
| FCC.gov Sources | FCC.gov 8768107, FCC.gov 8767772 |
