STK7049 Wireless Controller Test Setup Photos - FCC ID 2BDA4STK-7049
FCC ID 2BDA4STK-7049
Test Setup Photos
Wireless Controller
Document preview loads when visible.
Document Details
| FCC ID | 2BDA4STK-7049 |
|---|---|
| Document ID | 7705826 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Applicant | Hubei Saitake Electronic Co., Ltd. |
| Equipment Class | Wireless Controller |
| Product Code | STK7049 |
| Application ID | r1k+n62vKM3Vl1V3gk280w== |
| Application Purpose | Original Equipment |
| Application Date | 2024-10-03 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0034395657 |
| Test Firm | Shenzhen CCUT Quality Technology Co., Ltd. |
| Certified By | Siming Guo |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 03/28/2025 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2024-09-28 |
| Available | 2025-03-28 |
| Created | 2024-09-23 |
| Modified | 2024-09-23 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 305965 |
| File SHA-256 | 0c6928d2a6071441ab3a7f42907fce003df6e54e8e90443032fa7eb17f58f2ba |
| PDF Metadata Author | Sem |
| PDF Metadata Producer | Sem Microsoft® Word 2021 |
| FCC.gov Sources | FCC.gov 7705826 |
