S078 JC wireless controller Test Setup Photos - FCC ID 2BDAI-S078
FCC ID 2BDAI-S078
Test Setup Photos
JC wireless controller
Document preview loads when visible.
Document Details
| FCC ID | 2BDAI-S078 |
|---|---|
| Document ID | 6888670 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Applicant | Shenzhen Yuhong Electronic Technology Co., Ltd. |
| Equipment Class | JC wireless controller |
| Product Code | S078 |
| Application ID | 0/APc/EH57TO6ihQAoL7nA== |
| Application Purpose | Original Equipment |
| Application Date | 2023-11-01 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0034390765 |
| Test Firm | Shenzhen HongBiao Certification& Testing Co., Ltd |
| Certified By | Zhaoming Wu |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 04/29/2024 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2023-10-31 |
| Available | 2024-04-29 |
| Created | 2023-10-27 |
| Modified | 2023-10-30 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 484661 |
| File SHA-256 | f33e01e4a26f40179c6225ff1ca0b70df6653526397ea85c83a6dafa97ad95f2 |
| PDF Metadata Producer | Microsoft® Word 2019 Microsoft® Word 2019 |
| FCC.gov Sources | FCC.gov 6888670 |
