Z05300M 300M WiFi REPEATER Test Setup Photos - FCC ID 2BF65-Z05-300M

FCC ID 2BF65-Z05-300M

Test Setup Photos

300M WiFi REPEATER

by Shenzhen Shenshui Innovation Technology Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2BF65-Z05-300M
Document ID9399760
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleMeasurement Report
ApplicantShenzhen Shenshui Innovation Technology Co., Ltd.
Equipment Class300M WiFi REPEATER
Product CodeZ05300M
Application IDhynu+jz2LHx/qpsIjhceaQ==
Application PurposeOriginal Equipment
Application Date2026-06-24
Frequency Range2412-2462 MHz
FRN0035358878
Test FirmBTL Inc. (Dongguan)
Certified ByRose Liu Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Modular EquipmentDoes not apply
Composite DeviceNo
Submitted2026-06-18
Available2026-06-24
Created2026-06-16
Modified2026-06-16
Pages6
File TypeAdobe Acrobat PDF
File Size1909092
File SHA-256153394d5c4dfd64e82a19f5531a888e7d903274f7a6650c8bc4dcfa2dc38bed9
PDF Metadata AuthorKent
PDF Metadata ProducerKent Adobe PDF Library 19.12.66
FCC.gov SourcesFCC.gov 9399760
