ISSMP1ZA Vehicle Intelligent Safety... - FCC ID 2BFLQISSMP1ZA

FCC ID 2BFLQISSMP1ZA

Test Setup Photos.pdf

Vehicle Intelligent Safety System (ISS) utilising Wi-Fi, Bluetooth, LTE, UWB/RTLS, GNSS and ISM technologies.

by MPI Holdings FZE

Document preview loads when visible.

Document Details

FCC ID2BFLQISSMP1ZA
Document ID7804732
Document TypeTest Setup Photos
DescriptionTest Setup Photos.pdf
ApplicantMPI Holdings FZE
Equipment ClassVehicle Intelligent Safety System (ISS) utilising Wi-Fi, Bluetooth, LTE, UWB/RTLS, GNSS and ISM technologies.
Product CodeISSMP1ZA
Application IDHFoJjZhZNYSf10XKr7V92g==
Application PurposeOriginal Equipment
Application Date2024-11-19
Frequency Range915-928 MHz
FRN0035185602
Test FirmTUV SUD Limited
Certified ByStephen Milliken
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date05/03/2025
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2024-11-07
Available2025-05-03
Created2024-11-07
Modified2024-11-07
Pages16
File TypeAdobe Acrobat PDF
File Size1269405
File SHA-256d9409e0ffc5e99e2ea24933ada4af31ded01fdb519f5e5adafe086133434f29b
PDF Metadata ProducerAdobe Acrobat 24.3 Adobe Acrobat 24.3 Image Conversion Plug-in
FCC.gov SourcesFCC.gov 7804732
