M567BT Portable Radio Test Setup Photos - FCC ID 2BMIA-M567BT

FCC ID 2BMIA-M567BT

Test Setup Photos

Portable Radio

by Shenzhen Yage Trading Co., LTD.

Document preview loads when visible.

Document Details

FCC ID2BMIA-M567BT
Document ID7872738
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Title55013
ApplicantShenzhen Yage Trading Co., LTD.
Equipment ClassPortable Radio
Product CodeM567BT
Application IDy2JGB3Hd+ffvRzn/L7MHqQ==
Application PurposeOriginal Equipment
Application Date2024-12-03
Frequency Range2402-2480 MHz
FRN0036348233
Test FirmShenzhen CTB Testing Technology Co., Ltd.
Certified ByBruce Yang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/01/2025
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2024-12-03
Available2024-12-03
Created2024-12-03
Modified0002-01-01
Pages2
File TypeAdobe Acrobat PDF
File Size291408
File SHA-25673a25e5cddff9b057e2ed2deaa74506ca73509782fa386cce836d0f170ec12d9
PDF Metadata AuthorJade
PDF Metadata ProducerMicrosoft® Word 2016 Microsoft® Word 2016
FCC.gov SourcesFCC.gov 7872738
