TL7002WF WIFI Module Teardown Internal... - FCC ID 2BOGT-TL7002-WF
FCC ID 2BOGT-TL7002-WF
Internal Photos
WIFI Module
Document preview loads when visible.
Document Details
| FCC ID | 2BOGT-TL7002-WF |
|---|---|
| Document ID | 8407415 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | Internal photos |
| Applicant | GUANGDONG PHNIX ECO-ERERGY SOLUTION LTD |
| Equipment Class | WIFI Module |
| Product Code | TL7002WF |
| Application ID | /8o1W/y1QingO0merV1wAA== |
| Application Purpose | Original Equipment |
| Application Date | 2025-06-23 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0036654986 |
| Test Firm | Intertek Testing Services Shenzhen LTD., Guangzhou |
| Certified By | Ace Yao Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2025-06-23 |
| Available | 2025-06-23 |
| Created | 2025-06-13 |
| Modified | 2025-06-13 |
| Pages | 7 |
| File Type | Adobe Acrobat PDF |
| File Size | 1753922 |
| File SHA-256 | f9cb9246f512659f0483314f4598b03a68d7d2a351236409faef8beb3cdf13c8 |
| PDF Metadata Author | ace.yao |
| PDF Metadata Producer | GPL Ghostscript 10.03.1 ace.yao |
| FCC.gov Sources | FCC.gov 8407415 |
