QJEX Wireless Earbuds Teardown Internal Photos - FCC ID 2BONE-QJEX

FCC ID 2BONE-QJEX

Internal Photos

Wireless Earbuds

by SHENZHEN JIECHEN TECHNOLOGY CO.,LTD

Document preview loads when visible.

Document Details

FCC ID2BONE-QJEX
Document ID8327974
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleHD 271 S1
ApplicantSHENZHEN JIECHEN TECHNOLOGY CO.,LTD
Equipment ClassWireless Earbuds
Product CodeQJEX
Application IDXuubXaOby2IGS0NtEvEWWQ==
Application PurposeOriginal Equipment
Application Date2025-05-26
Frequency Range2402-2480 MHz
FRN0036891323
Test FirmDongguan Yaxu (AiT) Technology Limited
Certified Byxiangfu Tan manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2025-05-26
Available2025-05-26
Created2025-05-23
Modified2025-05-26
Pages10
File TypeAdobe Acrobat PDF
File Size4550341
File SHA-256d13f5caadd933771bb59deda18b20afd7f6dc91302c8f2b0cdd0c85785ee1f14
PDF Metadata AuthorAllo
PDF Metadata ProducerWPS 文字
FCC.gov SourcesFCC.gov 8327974
