DB01 dubbing box Teardown Internal Photos - FCC ID 2BQ6DDB01
FCC ID 2BQ6DDB01
Internal Photos
dubbing box
Document preview loads when visible.
Document Details
| FCC ID | 2BQ6DDB01 |
|---|---|
| Document ID | 8638600 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | YOU TELL LIMITED |
| Equipment Class | dubbing box |
| Product Code | DB01 |
| Application ID | ke4XM80H3GzhEUDZqJF3fA== |
| Application Purpose | Original Equipment |
| Application Date | 2025-09-09 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0037310984 |
| Test Firm | Shenzhen Morlab Communications Technology Co. Ltd. |
| Certified By | Wendy Zhan |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 03/03/2026 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2025-09-03 |
| Available | 2026-03-03 |
| Created | 2025-08-27 |
| Modified | 2025-08-27 |
| Pages | 9 |
| File Type | Adobe Acrobat PDF |
| File Size | 1525969 |
| File SHA-256 | e4030aa93af8206f7fa386c08a90f2e3e6e02f49ae3b59f8579f96a3cf45db06 |
| PDF Metadata Producer | Microsoft® Office Word 2007 Microsoft® Office Word 2007 |
| FCC.gov Sources | FCC.gov 8638600 |
