05SPUH External HDD Storage Block Diagram - FCC ID A3L05SPUH

FCC ID A3L05SPUH

Block Diagram

External HDD Storage

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3L05SPUH
Document ID546223
Document TypeBlock Diagram
DescriptionBlock Diagram
Document Titleuntitled
ApplicantSamsung Electronics Co Ltd
Equipment ClassExternal HDD Storage
Product Code05SPUH
Application IDV8KX6+lKck1Jo59a7Z3y9g==
Application PurposeOriginal Equipment
Application Date2005-05-27
FRN0027908797
Test FirmEMC Compliance LTD
Certified ByMin-Seok Chung Agent
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-05-27
Available2005-05-27
Created2005-05-14
Modified2005-05-14
Pages1
File TypeAdobe Acrobat PDF
File Size39948
File SHA-25604aa84d8b70537b8a23beb0ddcc7527a54d6dfc188e85eeeabb8cfc597e122db
PDF Metadata ProducerAcrobat Distiller 6.0.1 (Windows)
FCC.gov SourcesFCC.gov 546223
