FCC ID A3LATKM052000
IoT Module
by Samsung Electronics Co Ltd
Grantee Code: A3L Product Code: ATKM052000
Latest application date: 2016-06-14
Device Images
FCC ID Device Details
| FCC ID | A3LATKM052000 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | A3L |
| Product Code | ATKM052000 |
| Applicant Business | Samsung Electronics Co Ltd 🇺🇸 |
| Related Domains |  samsung.com |
| Equipment Class | IoT Module |
| Test Firm | Nemko Korea Co.,Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-06-14 |
| 5180-5220 MHz | Original Equipment | 2016-04-21 |
| 2402-2480 MHz | Original Equipment | 2016-04-21 |
| 2402-2480 MHz | Original Equipment | 2016-04-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-12-11 | PDF 127.4 KB |
| Users Manual | Users Manual | 2016-06-05 | PDF 535.8 KB |
| Internal Photos | Internal Photos | 2016-06-05 | PDF 5 MB |
| External Photos | External Photos | 2016-12-11 | PDF 5 MB |
| External Photos | External Photos | 2016-06-05 | PDF 5 MB |
| Label and Label Location | ID Label/Location Info | 2016-06-14 | PDF 56.1 KB |
| Label and Label Location | ID Label/Location Info | 2016-04-21 | PDF 81.6 KB |
| Label and Label Location info | ID Label/Location Info | 2016-04-21 | PDF 81.6 KB |
| Test Setup Photos | Test Setup Photos | 2016-12-11 | PDF 543.8 KB |
| Test Report | Test Report | 2016-06-14 | PDF 5.5 MB |
| Test Report | Test Report | 2016-04-21 | PDF 4.5 MB |
| Test Report | Test Report | 2016-04-21 | PDF 4 MB |
| Test Report | Test Report | 2016-04-21 | PDF 1.5 MB |
| Cover Letters | Cover Letter(s) | 2016-06-14 | PDF 103.8 KB |
| Cover Letter | Cover Letter(s) | 2016-04-21 | PDF 16.7 KB |
| Cover Letters | Cover Letter(s) | 2016-04-21 | PDF 28.9 KB |
| RF Exposure info | RF Exposure Info | 2016-06-14 | PDF 67.7 KB |
| Parts List | Parts List/Tune Up Info | 2016-04-21 | PDF 202.9 KB |
| RF Exposure info | RF Exposure Info | 2016-04-21 | PDF 65.2 KB |
| Block Diagram Metadata only | Block Diagram | PDF 32.1 KB | |
| Schematics Metadata only | Schematics | PDF 549.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 1 MB | |
| SDR software/Security info Metadata only | SDR Software/Security Inf | PDF 103.8 KB | |
| SDR software/security info Metadata only | SDR Software/Security Inf | PDF 103.8 KB | |
| Sofrware/Security Info Metadata only | SDR Software/Security Inf | PDF 103.8 KB |
Application Information
| Application ID | Z5pL/2/gXujMdzy5P3iwkQ== |
|---|---|
| Final Action Date | 2016-06-14 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0027908797 |
| Model | ATKM052000 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | IoT Module |
| Responsible Party | Jenni Chun, General Manager, j1.chun@samsung.com , 973-808-6375 |
| Test Firm | Hyun-ho Kim, Nemko Korea Co.,Ltd., hyunho.kim@nemko.com  , 82-31-322-2333 |
| TCB Email | Stuart.Beck@nemko.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 12/11/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. This device has a 20 MHz, 40 MHz and 80MHz bandwidth mode. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in this filing. End-users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance. This device is restricted to indoor-only use for the 5150.0 - 5250.0 MHz band. This device complies with the Dynamic Frequency Selection (DFS) requirements of Report and Order FCC 06-96 as a Client only without Radar Detection. |
