GTN7000B Cellular/PCS GSM/EDGE/WCDMA Phone... - FCC ID A3LGTN7000B

FCC ID A3LGTN7000B

Test Setup Photos

Cellular/PCS GSM/EDGE/WCDMA Phone with WLAN and Bluetooth

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LGTN7000B
Document ID1596639
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Title22-24 Test Setup Photographs
ApplicantSamsung Electronics Co Ltd
Equipment ClassCellular/PCS GSM/EDGE/WCDMA Phone with WLAN and Bluetooth
Product CodeGTN7000B
Application IDiCh+8/xxRkcs89gnwiCItg==
Application PurposeOriginal Equipment
Application Date2011-12-06
Frequency Range1850.2-1909.8 MHz
FRN0005810205
Test FirmPCTEST Engineering Laboratory, Inc.
Certified ByPeter Ra
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/03/2012
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2011-12-06
Available2012-06-03
Created2011-11-18
Modified2011-12-06
Pages2
File TypeAdobe Acrobat PDF
File Size484372
File SHA-256aaada19e1544f0f493a588f7cbe3b3812e61ba9d4d6c26ed0990d8be98be44fb
PDF Metadata Authorprigolage
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 10.1.1 (Windows)
FCC.gov SourcesFCC.gov 1596639
