HXD7 Compact Component System Block Diagram - FCC ID A3LHXD7

FCC ID A3LHXD7

Block Diagram

Compact Component System

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LHXD7
Document ID527996
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleCR-5000 plot output
ApplicantSamsung Electronics Co Ltd
Equipment ClassCompact Component System
Product CodeHXD7
Application IDXvIxzhm+jr2YGMK/mctEJA==
Application PurposeOriginal Equipment
Application Date2005-03-30
FRN0027908797
Test FirmSAMSUNG ELECTRONICS CO., LTD.
Certified ByRandy Ortanez President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-03-30
Available2005-03-30
Created2005-03-24
Modified2005-03-24
Pages1
File TypeAdobe Acrobat PDF
File Size76034
File SHA-2560b9148d1d4ecc8bdb406040c2361ece5f9f57f0cfa33d896a90222dece6b105c
PDF Metadata Authorsym
PDF Metadata ProducerpdfFactory Pro www.pdffactory.com pdfFactory Pro 2.21 (Windows XP Korean)
FCC.gov SourcesFCC.gov 527996
