FCC ID A3LLS19E310
LCD Monitor
by Samsung Electronics Co Ltd
Grantee Code: A3L Product Code: LS19E310
Latest application date: 2015-11-05
Device Images
FCC ID Device Details
| FCC ID | A3LLS19E310 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | A3L |
| Product Code | LS19E310 |
| Applicant Business | Samsung Electronics Co Ltd 🇺🇸 |
| Related Domains |  samsung.com |
| Equipment Class | LCD Monitor |
| Test Firm | CHINA SAMSUNG QUALITY ASSURANCE LABORATORY |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| user manual | Users Manual | 2015-11-05 | PDF 4 MB |
| user manual-2 | Users Manual | 2015-11-05 | PDF 1.3 MB |
| internal photos_v2 | Internal Photos | 2015-11-05 | PDF 402.6 KB |
| external photos_v1 | External Photos | 2015-11-05 | PDF 346.7 KB |
| label location_v1 | ID Label/Location Info | 2015-11-05 | PDF 149 KB |
| test setup photos | Test Setup Photos | 2015-11-05 | PDF 393.5 KB |
| LBE20146486_LS19E31x_ITE_FCC Report | Test Report | 2015-11-05 | PDF 2.5 MB |
| LBE20146494_LS19E31x_ITE_FCC Report | Test Report | 2015-11-05 | PDF 2.5 MB |
| ACB-Form-FCC-confidentiality-Letters A3LLS19E310 | Cover Letter(s) | 2015-11-05 | PDF 251.2 KB |
| Confidential_SE310_ Block_v1 Metadata only | Block Diagram | PDF 177.1 KB | |
| Confidential_BN44-00718A circuit diagram Metadata only | Schematics | PDF 57.9 KB | |
| Confidential_SE310_21.5_27_2118C_v1 Metadata only | Schematics | PDF 416.4 KB | |
| Confidential_Operational Description_v1 Metadata only | Operational Description | PDF 301.8 KB |
Application Information
| Application ID | 9+woXG+VVoesvAZA34c7Cg== |
|---|---|
| Final Action Date | 2015-11-05 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005810205 |
| Model | LS19E310 |
| Equipment Class | JBP - Part 15 Class B Computing Device Peripheral |
| Device Description | LCD Monitor |
| Responsible Party | Jenni Chun, General Manager, j1.chun@samsung.com , 973-808-6375 |
| Technical Contact | li xiao, China Samsung Quality Assurance Laboratory, xiao.li@samsung.com , 022-23961234 |
| Non-Technical Contact | Zhang qi, Tianjin Samsung Electronics Co., LTD., qi00.zhang@samsung.com , 022-23961234 |
| Test Firm | Zhongyuan Gao, CHINA SAMSUNG QUALITY ASSURANCE LABORATORY, zhongyuan.gao@samsung.com , 86-22-2396-1234 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Maximum resolution: 1366 x 768@60Hz |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 9+woXG+VVoesvAZA34c7Cg== | 2015-11-05 | Original Equipment |
Grants
TCB Grant - Application 9+woXG+VVoesvAZA34c7Cg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 11/05/2015 Application Dated: 11/03/2015 |
| Samsung Electronics Co Ltd |
| 19 Chapin Rd., Building D |
| Pine Brook, NJ 07058 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LLS19E310 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | LCD Monitor |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 19 | 15B | - |
| Maximum resolution: 1366 x 768@60Hz |
| 19: | This device must be marketed with a shielded interface cable which incorporates ferrite cores equal in quantity and type to those used during Certification testing. |
EAS Grant - Application 9+woXG+VVoesvAZA34c7Cg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Samsung Electronics Co Ltd 19 Chapin Rd., Building D Pine Brook, NJ 07058 United States |
Date of Grant: 11/05/2015 Application Dated: 11/03/2015 |
| Attention: Jenni Chun , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | A3LLS19E310 |
| Name of Grantee: | Samsung Electronics Co Ltd |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | LCD Monitor |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 19 | 15B | - |
| Maximum resolution: 1366 x 768@60Hz |
| 19: | This device must be marketed with a shielded interface cable which incorporates ferrite cores equal in quantity and type to those used during Certification testing. |
