OTR7MT Microwave Oven Schematics - FCC ID A3LOTR7MT

FCC ID A3LOTR7MT

Schematics

Microwave Oven

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LOTR7MT
Document ID179843
Document TypeSchematics
DescriptionSchematics
ApplicantSamsung Electronics Co Ltd
Equipment ClassMicrowave Oven
Product CodeOTR7MT
Application ID703WCYUJ2bvEUtXYr+3lRA==
Application PurposeOriginal Equipment
Application Date2001-11-16
Frequency Range2450 MHz
FRN0027908797
Test FirmSamsung Electronics Co., Ltd.
Certified ByRandy Ortanez President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2001-11-16
Available2001-11-16
Created2001-08-12
Modified2001-11-12
Pages1
File TypeAdobe Acrobat PDF
File Size241570
File SHA-25671b6d0202b4d0d6e1d577d8745786a6e7233ca02de141dc1b274e81a55d79bbe
PDF Metadata ProducerAdobe PDF Library 2.0
FCC.gov SourcesFCC.gov 179843
