SCX4828FN Multi Function Printer Block Diagram - FCC ID A3LSCX4828FN
FCC ID A3LSCX4828FN
Block Diagram
Multi Function Printer
Document preview loads when visible.
Document Details
| FCC ID | A3LSCX4828FN |
|---|---|
| Document ID | 912052 |
| Document Type | Block Diagram |
| Description | Block Diagram |
| Document Title | Microsoft PowerPoint - Microsoft PowerPoint .ppt |
| Applicant | Samsung Electronics Co Ltd |
| Equipment Class | Multi Function Printer |
| Product Code | SCX4828FN |
| Application ID | B7lLMplgfsjiK/9gZlH/WQ== |
| Application Purpose | Original Equipment |
| Application Date | 2008-03-10 |
| FRN | 0005810205 |
| Test Firm | Samsung Electronics EMC Laboratory |
| Certified By | Randy Ortanez President |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2008-03-10 |
| Available | 2008-03-10 |
| Created | 2008-03-03 |
| Modified | 2008-03-10 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 313389 |
| File SHA-256 | b3dbabf17b3f33993fdcd633cbbfa179e9353eb21ae3c8df551f16fb89e8c106 |
| PDF Metadata Author | Jinwoo Noh |
| PDF Metadata Creator | PScript5.dll Version 5.2.2 |
| PDF Metadata Producer | Acrobat Distiller 6.0 (Windows) |
| FCC.gov Sources | FCC.gov 912052 |
