SGHP200 Single-Band PCS GSM/ EDGE Phone with... - FCC ID A3LSGHP200

FCC ID A3LSGHP200

Internal Photos

Single-Band PCS GSM/ EDGE Phone with WLAN

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSGHP200
Document ID669696
Document TypeInternal Photos
DescriptionInternal Photos
Document TitlePhone footer_2006
ApplicantSamsung Electronics Co Ltd
Equipment ClassSingle-Band PCS GSM/ EDGE Phone with WLAN
Product CodeSGHP200
Application IDmbZl8NfB7jCt8cmh3PbRkw==
Application PurposeOriginal Equipment
Application Date2006-06-15
Frequency Range2412-2462 MHz
FRN0027908797
Test FirmPCTEST Engineering Laboratory, Inc.
Certified ByRandy Ortanez President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/30/2006
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartYes
Submitted2006-06-16
Available2006-07-30
Created2006-06-15
Modified2006-06-16
Pages8
File TypeAdobe Acrobat PDF
File Size1156159
File SHA-256431e6adfab7dd3d44d9effc3fa69bbdec30147a76a073d35536944ee472b3e97
PDF Metadata AuthorOwner
PDF Metadata ProducerAcrobat PDFWriter 5.0 for Windows NT Owner
FCC.gov SourcesFCC.gov 669696, FCC.gov 669680
