SMA326U Mobile Phone Label Diagram - FCC ID A3LSMA326U

FCC ID A3LSMA326U

A3LSMA326U_E-label description_rev.1

Mobile Phone

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMA326U
Document ID5148224
Document TypeID Label/Location Info
DescriptionA3LSMA326U_E-label description_rev.1
ApplicantSamsung Electronics Co Ltd
Equipment ClassMobile Phone
Product CodeSMA326U
Application IDXXDea/ZMCUCIwetNB9pUEg==
Application PurposeOriginal Equipment
Application Date2021-03-08
Frequency Range3552.5-3697.5 MHz
FRN0027908797
Test FirmHCT Co., Ltd.
Certified ByJenni Chun
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date09/04/2021
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2021-03-04
Available2021-03-08
Created2018-08-29
Modified2021-02-19
Pages2
File TypeAdobe Acrobat PDF
File Size260060
File SHA-25657f2d06fbb0d111eac2b5588a0c7cc1ed4e6e20df20c11d02f286c4ae1195969
PDF Metadata AuthorWindows 사용자
PDF Metadata ProducerWindows 사용자 Adobe PDF Library 11.0
FCC.gov SourcesFCC.gov 5148224, FCC.gov 5148086, FCC.gov 5148004, FCC.gov 5147929, FCC.gov 5147865, FCC.gov 5147851, FCC.gov 5147836, FCC.gov 5147821
