SMG610M Multi-band GSM/EDGE/UMTS/LTE Phone... - FCC ID A3LSMG610M

FCC ID A3LSMG610M

HAC RFE Report

Multi-band GSM/EDGE/UMTS/LTE Phone with Bluetooth, WLAN and ANT+

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMG610M
Document ID3136654
Document TypeTest Report
DescriptionHAC RFE Report
ApplicantSamsung Electronics Co Ltd
Equipment ClassMulti-band GSM/EDGE/UMTS/LTE Phone with Bluetooth, WLAN and ANT+
Product CodeSMG610M
Application ID2lK/6B/B+elSMY0OMj6JSg==
Application PurposeOriginal Equipment
Application Date2016-09-16
Frequency Range2402-2480 MHz
FRN0027908797
Test FirmPCTEST Engineering Laboratory, Inc.
Certified ByChan Ho Youn
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date03/15/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2016-09-16
Available2016-09-16
Created2016-09-08
Modified2016-09-16
Pages62
File TypeAdobe Acrobat PDF
File Size2181222
File SHA-2567e95884cf3c56455dce83e8f95f570df968e20ee3f3c83fa56b789db958befb0
PDF Metadata ProducerAcrobat Distiller 10.1.16 (Windows)
FCC.gov SourcesFCC.gov 3136654
