SMG720N0 Mobile Phone Test Report - FCC ID A3LSMG720N0

FCC ID A3LSMG720N0

ANT+ TestReport

Mobile Phone

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMG720N0
Document ID2473374
Document TypeTest Report
DescriptionANT+ TestReport
Document Title© 2001 PCTEST Engineering Lab
ApplicantSamsung Electronics Co Ltd
Equipment ClassMobile Phone
Product CodeSMG720N0
Application IDQ3QXqtODzRjQX/G5+Fijsg==
Application PurposeOriginal Equipment
Application Date2014-12-15
Frequency Range2402-2480 MHz
FRN0005810205
Test FirmHCT Co., LTD
Certified ByChan Ho Youn
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/13/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-12-15
Available2014-12-15
Created2014-12-09
Modified2014-12-09
Pages31
File TypeAdobe Acrobat PDF
File Size1559738
File SHA-256646549eaf2e102a14c4cdde212839b1282bb172b57fa4cc1eb4a36dda511f2f8
PDF Metadata Author박근호
PDF Metadata Producer박근호 Adobe PDF Library 11.0
FCC.gov SourcesFCC.gov 2473374
