SMG800H Cellular/ PCS GSM/ EDGE/ UMTS Phone... - FCC ID A3LSMG800H

FCC ID A3LSMG800H

Test Setup Photos

Cellular/ PCS GSM/ EDGE/ UMTS Phone with WLAN and Bluetooth

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMG800H
Document ID2314628
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitlezFCCMASTER 15C Test Setup Photosm
ApplicantSamsung Electronics Co Ltd
Equipment ClassCellular/ PCS GSM/ EDGE/ UMTS Phone with WLAN and Bluetooth
Product CodeSMG800H
Application IDhgkV4H0B7x+u8/OzgKW3EQ==
Application PurposeOriginal Equipment
Application Date2014-07-03
Frequency Range2402-2480 MHz
FRN0027908797
Test FirmPCTEST Engineering Laboratory, Inc.
Certified BySang Kyung (Peter) Ra
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/30/2014
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-07-03
Available2014-12-30
Created2018-08-01
Modified2018-08-01
Pages3
File TypeAdobe Acrobat PDF
File Size292643
File SHA-256b75024e8f0f82f74ea42034dbf2b2a8f47c38e8d36c64fb0cf37c139efc02f69
PDF Metadata Authormohammad.walid
PDF Metadata ProducerGPL Ghostscript 9.21 mohammad.walid
FCC.gov SourcesFCC.gov 2314628, FCC.gov 2314609, FCC.gov 2314593
