  4. HAC RFE Test Report

SMJ260T1 Multi-band GSM/EDGE/UMTS/LTE Phone... - FCC ID A3LSMJ260T1

FCC ID A3LSMJ260T1

HAC RFE Test Report

Multi-band GSM/EDGE/UMTS/LTE Phone with Bluetooth and WLAN

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMJ260T1
Document ID4050093
Document TypeTest Report
DescriptionHAC RFE Test Report
ApplicantSamsung Electronics Co Ltd
Equipment ClassMulti-band GSM/EDGE/UMTS/LTE Phone with Bluetooth and WLAN
Product CodeSMJ260T1
Application IDxtaPiIRqrY2Q0jLOnWAcXg==
Application PurposeOriginal Equipment
Application Date2018-10-26
Frequency Range2402-2480 MHz
FRN0027908797
Test FirmPCTEST Engineering Laboratory, LLC
Certified ByJenni Chun
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date04/24/2019
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2018-10-26
Available2018-10-26
Created2018-10-26
Modified2018-10-26
Pages66
File TypeAdobe Acrobat PDF
File Size2398373
File SHA-25616fbeff6547b4340cb09cf2bb69ed3461ea6bc15e1bf19d5226fcff668e2023a
PDF Metadata ProducerAcrobat Distiller 15.0 (Windows)
FCC.gov SourcesFCC.gov 4050093, FCC.gov 4050070
