SMJ327P Multi-band CDMA/GSM/EDGE/UMTS/LTE... - FCC ID A3LSMJ327P

FCC ID A3LSMJ327P

HAC RFE Test Report

Multi-band CDMA/GSM/EDGE/UMTS/LTE Phone with Bluetooth and WLAN

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMJ327P
Document ID3184293
Document TypeTest Report
DescriptionHAC RFE Test Report
ApplicantSamsung Electronics Co Ltd
Equipment ClassMulti-band CDMA/GSM/EDGE/UMTS/LTE Phone with Bluetooth and WLAN
Product CodeSMJ327P
Application IDP+RMQPURpuoiVsVgfrpscA==
Application PurposeOriginal Equipment
Application Date2016-10-24
Frequency Range1710.7-1754.3 MHz
FRN0027908797
Test FirmPCTEST Engineering Laboratory, Inc.
Certified ByChan Ho Youn
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date04/22/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2016-10-24
Available2016-10-24
Created2017-12-17
Modified2017-12-17
Pages61
File TypeAdobe Acrobat PDF
File Size4474425
File SHA-25686cafe41acea438cfad35d73b444bebc4a1e67156c6bcce3f4df7ef99faaddab
PDF Metadata ProducerGPL Ghostscript 9.18
FCC.gov SourcesFCC.gov 3184293, FCC.gov 3184307, FCC.gov 3184300, FCC.gov 3172850, FCC.gov 3172826, FCC.gov 3172802
