SMJ500F Multi-Band GSM/ EDGE/ WCDMA/ LTE... - FCC ID A3LSMJ500F

FCC ID A3LSMJ500F

Internal Photos

Multi-Band GSM/ EDGE/ WCDMA/ LTE Phone with WLAN, Bluetooth and ANT+

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMJ500F
Document ID2662839
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleSAMSUNG_SM-J500F_DS RF_INTERNAL PHOTO
ApplicantSamsung Electronics Co Ltd
Equipment ClassMulti-Band GSM/ EDGE/ WCDMA/ LTE Phone with WLAN, Bluetooth and ANT+
Product CodeSMJ500F
Application IDtlG046cC3E2GsUnCPopVKg==
Application PurposeOriginal Equipment
Application Date2015-06-30
Frequency Range1850.2-1909.8 MHz
FRN0005810205
Test FirmHCT Co., Ltd.
Certified ByChan Ho Youn
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/28/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-06-30
Available2015-12-28
Created2015-06-12
Modified2015-06-30
Pages20
File TypeAdobe Acrobat PDF
File Size1058096
File SHA-256f8f5232d1c470fe440f007d1bf6feb8665ffff9448a735acbd60c8e8639633f3
PDF Metadata Authori
PDF Metadata Produceri Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 2662839, FCC.gov 2662916, FCC.gov 2662903, FCC.gov 2662888, FCC.gov 2662859
