SMJ701FB Mobile phone Label Diagram - FCC ID A3LSMJ701FB

FCC ID A3LSMJ701FB

Label format and location

Mobile phone

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMJ701FB
Document ID3972477
Document TypeID Label/Location Info
DescriptionLabel format and location
Document TitleA3LSMJ701FB Label locationx
ApplicantSamsung Electronics Co Ltd
Equipment ClassMobile phone
Product CodeSMJ701FB
Application IDjDHdBb4kMXebfsWZzxLcCA==
Application PurposeOriginal Equipment
Application Date2018-08-22
Frequency Range1850.2-1909.8 MHz
FRN0027908797
Test FirmHCT Co., Ltd.
Certified ByChan Ho, Youn
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date02/18/2019
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2018-08-22
Available2018-08-22
Created2018-08-15
Modified2018-08-15
Pages1
File TypeAdobe Acrobat PDF
File Size260758
File SHA-2564fec3a4205fa2ad5cd361f142d48e69e2c15ad7e1da4a892c60a48d5c6edd4f1
PDF Metadata Authoradmin
PDF Metadata Produceradmin Acrobat Distiller 10.1.16 (Windows)
