SMJ7109 Mobile Phone Test Report - FCC ID A3LSMJ7109
FCC ID A3LSMJ7109
Test Report_20160204_v1 - A3LSMJ7109_RF Test Report_CDMA
Mobile Phone
Document preview loads when visible.
Document Details
| FCC ID | A3LSMJ7109 |
|---|---|
| Document ID | 2902909 |
| Document Type | Test Report |
| Description | Test Report_20160204_v1 - A3LSMJ7109_RF Test Report_CDMA |
| Document Title | SAMSUNG_SM-J7109 RF Test Report_CDMA |
| Applicant | Samsung Electronics Co Ltd |
| Equipment Class | Mobile Phone |
| Product Code | SMJ7109 |
| Application ID | EFG3u81xW6TkBzRGHKRHLw== |
| Application Purpose | Original Equipment |
| Application Date | 2016-02-15 |
| Frequency Range | 1850.2-1909.8 MHz |
| FRN | 0005810205 |
| Test Firm | HCT Co., LTD |
| Certified By | EunMi Kim Agent |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 08/12/2016 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2016-02-15 |
| Available | 2016-02-15 |
| Created | 2017-11-18 |
| Modified | 2017-11-18 |
| Pages | 32 |
| File Type | Adobe Acrobat PDF |
| File Size | 1184790 |
| File SHA-256 | d5bcd9c682ed68e0660bc9320d66cad6f027e13c9c7deaabbcc2a44f34e17cc7 |
| PDF Metadata Author | i |
| PDF Metadata Producer | GPL Ghostscript 9.18 i |
| FCC.gov Sources | FCC.gov 2902909 |
