SMN7507 GSM/WCDMA Phone + Bluetooth... - FCC ID A3LSMN7507

FCC ID A3LSMN7507

Label Letter

GSM/WCDMA Phone + Bluetooth, DTS/UNII abgn & NFC & ANT+

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMN7507
Document ID2218950
Document TypeID Label/Location Info
DescriptionLabel Letter
Document Title[Sample]Label letter 130327
ApplicantSamsung Electronics Co Ltd
Equipment ClassGSM/WCDMA Phone + Bluetooth, DTS/UNII abgn & NFC & ANT+
Product CodeSMN7507
Application IDcgYRpjjjJTSsg7to0usmxQ==
Application PurposeOriginal Equipment
Application Date2014-03-18
FRN0027908797
Test FirmSAMSUNG ELECTRONICS EMC LABORATORY(R5)
Certified ByAna Amentado Agent
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date09/10/2014
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-03-18
Available2014-03-18
Created2013-08-14
Modified2014-03-10
Pages1
File TypeAdobe Acrobat PDF
File Size706985
File SHA-2563f21a6d71290a4e09dada927bbccb44668bf14c088dd8e04b9face91b0e4ef60
PDF Metadata Authorkijoong.kwon
PDF Metadata ProducerAcrobat Distiller 9.5.5 (Windows) kijoong.kwon
FCC.gov SourcesFCC.gov 2218950, FCC.gov 2218791, FCC.gov 2218767
