SMN7508V GSM/WCDMA Phone + Bluetooth... - FCC ID A3LSMN7508V

FCC ID A3LSMN7508V

Test Report

GSM/WCDMA Phone + Bluetooth, DTS/UNII abgn, NFC & ANT

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMN7508V
Document ID2198009
Document TypeTest Report
DescriptionTest Report
Document Title14U16931-1 FCC WWAN Report_Finalx
ApplicantSamsung Electronics Co Ltd
Equipment ClassGSM/WCDMA Phone + Bluetooth, DTS/UNII abgn, NFC & ANT
Product CodeSMN7508V
Application IDs9TcJbrK0bWJjmaJ7Py0hQ==
Application PurposeOriginal Equipment
Application Date2014-02-23
Frequency Range1850.2-1909.8 MHz
FRN0027908797
Test FirmCompliance Certification Services
Certified ByAna Amentado Agent
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date08/06/2014
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-02-23
Available2014-02-23
Created2014-02-15
Modified2014-02-15
Pages68
File TypeAdobe Acrobat PDF
File Size2466499
File SHA-256527cd6c6c8dec75d0862b9428dd069abd56b2f47d0bbae51cf50ee2f6399439b
PDF Metadata Author12701
PDF Metadata ProducerAcrobat Distiller 10.1.2 (Windows) 12701
FCC.gov SourcesFCC.gov 2198009
