SMR150R Bluetooth Headset Teardown Internal... - FCC ID A3LSMR150R

FCC ID A3LSMR150R

Internal Photos

Bluetooth Headset

by Samsung Electronics Co Ltd

Document preview loads when visible.

Document Details

FCC IDA3LSMR150R
Document ID3008856
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleInternal Photos_SM-R150R
ApplicantSamsung Electronics Co Ltd
Equipment ClassBluetooth Headset
Product CodeSMR150R
Application IDh74ZSpMD6NS/LJ3uK4OI0Q==
Application PurposeOriginal Equipment
Application Date2016-05-30
Frequency Range2402-2480 MHz
FRN0027908797
Test FirmSGS KOREA CO., Ltd.
Certified ByChan Ho Youn
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date11/26/2016
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2016-05-30
Available2016-11-26
Created2016-05-19
Modified2016-05-19
Pages3
File TypeAdobe Acrobat PDF
File Size102270
File SHA-256b2ffd8ae877b4cdaacac1a84c9ed2f4d283aa4e73c54b8b4aec09f10fa5c692a
PDF Metadata Authorgihee_hwang
PDF Metadata ProducerGaaiho PDF gihee_hwang
FCC.gov SourcesFCC.gov 3008856, FCC.gov 3008844
